First, the product overview:

"RRD-102V2.0"Stereo radio moduleFM Stereo radio Module) High sensitivity, low power consumption, ultra-small size FM stereo radio module. useRDA MicroelectronicsofRDA5807M(orRDA5802NM),This circuit has fewer peripheral components and a low noise figure. With a small size, low power consumption, low cost, simple application, the use of a wide range of advantages. Is a simple and easy to use and very cost-effective single chipFMStereo radio module. The following are the same as the "

A:mobileDVD,TV,MP3,MP4And so onFMFull band wireless receiver module. The following are the same as the "

B: Industrial and mining, business, campus, community, tourist areas and other public places stereo FM radio system. The following are the same as the "

C: Wireless audio and wireless stereo headset function. The following are the same as the "

D:GPSNavigation, television broadcasting system and other wireless FM radio. The following are the same as the "

E: High-end game and wireless audio electronic toys. The following are the same as the "

F: Mobile phones, mobile phones, intercom systems, mobile radio devices such as stereo radio. The following are the same as the "

G:PDASandNotebook PCSuch as peripheral applications. The following are the same as the "

Second, the functional characteristics:

A, Using generic102BCModule package, the user can directly replace the use, without changing the circuit design. The following are the same as the "

B, High sensitivity, low noise, anti-interference ability, very few external components, small size11 * 11.2MM Max), The use of extremely simple. The following are the same as the "

C,76-108MHzglobalFMBand compatibility (including Japan76-91MHzAnd Europe and the United States87.5-108.5 MHz). The following are the same as the "

D,I2CSerial data bus interface communication,Supports external reference clock input mode. The following are the same as the "

E, Fully integratedCOMSProcess single chip integrated circuit, power consumption is minimal. The following are the same as the "

F, Built-in high precisionA / D(Analog-to-digital converters) and digital frequency synthesizers. The following are the same as the "

G, Built-inLDOAdjustment, low power consumption, wide voltage range (2.7-3.6VDC). The following are the same as the "

H, Built-in noise cancellation, soft mute, bass boost circuit design. The following are the same as the "

I, High power32Load audio output, direct headphone splicing, no external audio driver zoom. The following are the same as the "

J, The application is simple, low cost, cost-effective.
