Описание товара
Brand NameNoneModel NumberQKMeasurement unitpiece/piecesEach pack1
Description
Product name: UHF 8 port Fixed Reader
Package size:180*128*28mm
General description:
UHF 8 port Fixed Reader is a high performance UHF RFID fixed reader. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. Support Android operating system, support 4G Wan communication. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.
Features:
Self-intellectual property;
Designed with Impinj R2000 RFID engine;
Support ISO18000-6C(EPC C1G2) , ISO18000-6B protocol tag;
860~868MHz/902~928MHz frequency band(frequency customization optional);
FHSS or Fix Frequency transmission, support RSSI, peak query tag speed up to 700pcs/s
RF output power up to 33dbm(adjustable);
8 SMA antenna port, support antenna detection;
4G platform MTK8735, nuclear base 1.3 GHz ARM®Cortex-A53, built-in Mali - T720 MP2;
Android 5.1/6.0 operating system;
RAM + ROM storage configuration: 1GB LPDDR3+8GB EMMC/2GB LPDDR3+16GB EMMC(optional).
Support 4 g networks, with Lord, vice 4G antenna interface ;
Support 2.4 G / 5 G dual-band WIFI;
Support bluetooth 4.0;
Support GPS location;
HDMI Type D interface, fastest support up to 5 gb/s transmission rate and 1920 x1080p high-definition format video output;
Support USB OTG 2.0;
Support 10 M/ 100M adaptive network interface;
Support RS232 interface;
Low power dissipation with single +9~24V DC power supply;
Support multiple opto-isolator GPIO, 4 channel input and output, isolation voltage VRMS>3kV.
Support secondary development and remote online firmware upgrading;
Small and exquisite design, IP43 protection, meet the demand for variety of applications.
Characteristics:
Absolute Maximum Rating
| ITEM | SYMBOL | VALUE | UNIT |
| Power Supply | VCC | 30 | V |
| Operating Temp. | TOPR | -30～+70 | ℃ |
| Storage Temp. | TSTR | -40～+85 | ℃ |
| humidity | H | <95%（+25℃） |
Electrical Specification
Under TA＝25℃，VCC＝+12V unless specified
| ITEM | SYMBOL | MIN | TYP | MAX | UNIT |
| Working Voltage | VCC | 9 | 12 | 24 | V |
| Working Current |
IC | 1.5 | 2.5 | A | |
| Size | L x W x H | 180 x 128 x 28 Aaa Aaa | Mm |
UHF Rfid specification
| ITEM | SYMBOL | MIN | TYP | MAX | UNIT |
| Working frequency | Freq | 860 | 960 | MHz | |
| Output power | Prf | 33 | dBm | ||
| Output power accuracy | Aprf | +/-1 | db | ||
| Output power flatness | Fprf | +/-0.2 | db | ||
| receive sensitivity | Sr | -85 | dBm |
Mobile communication Specification
| ITEM | SYMBOL | explanation |
| Band | Fb | 2G GSM : B2 B3 B5 B8(B2 optional) 3G WCDMA: B1 B2 B5 B8(B2optional) 3G TD-SCDMA: B34 B39 4G LTE: B1 B3 B7 B38 B39 B40 B41(B7 optional) CDMA2000&1X EVDO: BC0 |
| Transmitted power
| TPrf | Class 4(2W) Class 1(1W) Class 3(0.25W):Pmax< 23dBm |
| Data rate | Dbr | LTE Downlink: 150Mbps LTE Uplink: 50Mbps HSDPA: 42.2Mbps HSUPA: 11.5Mbps TD-HSDPA: 2.8Mbps |
| SIM card | SC | SIM/USIM card, working voltage:1.8V、3V |
WiFi/Bluetooth specification
| ITEM | SYMBOL | explanation |
| WiFi | WIFI network protocol: 802.11 b/g/n/a security encryption: WFA WPA/WPA2 transmitted power: Pmax <20dBm | |
| Bluetooth | Bluetooth features: V2.1+EDR, 3.0+HS, V4.0+HS Receiver sensitivity: GFSK -94dBm, DQPSK -93dBm, 8-DPSK -87.5dBm |
GPS specification
| ITEM | SYMBOL | explanation |
| GPS | frequency: 1575.42MHZ carrier to noise ratio：41db/Hz Sensitivity:-163dBm |
Interface:
1.GPS antenna
2.4G communication vice antenna
3.4G communication Lord antenna
4.WiFi/Bluetooth antenna
5.4G communication SIM card slot
6.DC power supply JACK
| No. | Symbol | Comment |
| Central | PWR | +9V~+24V DC |
| Outer | GND | GND |
7.USB interface
8.HDMI interface
9.TCPIP network interface RJ45
10.Serial communication interface RS232 （DB9 Female）
| No. | Symbol | Comment |
| 1 | NC | reservation |
| 2 | TXD | Serial communication data output |
| 3 | RXD | Serial communication data input |
| 4 | NC | reservation |
| 5 | GND | signal ground |
| 6 | NC | reservation |
| 7 | NC | reservation |
| 8 | NC | reservation |
| 9 | NC | reservation |
11.GPIO interface
12.Debugging/downloading USB interface
13.USB interface
14.System restoration RESET button
15.USB interface
16.SMA antenna interface ANT1~ANT8
